Pot washer MEIKO M-iClean PF-S

Servicing and technical data

Experience the machine

ADVANTAGES

  • Huge volumetric capacity in a small footprint

  • Door folds down – for easy access and cleaning

  • Intuitive operating concept – keeps things clear

  • Premium materials – for reliability and stability

  • Integrated hold-down grid (optional) – a permanent part of the rack that keeps lightweight washware in place

  • MEIKO AirConcept heat recovery (optional) – improves the indoor climate and prevents visible steam emissions

Less than
1 M2
FLOOR SPACE

This dishwashing machine stands out for its small size and footprint, making it ideal for workspaces where every centimetre counts. The combination of small footprint and large wash chamber meets the needs of many sectors, from bakeries to food retailers to the hospitality industry.

POT WASHER

MEIKO M-iClean PF-S
Rack dimension 608 x 700 mm
Entry height 830 mm
Dimensions (W x Hmin x D)775 x 1868 (2271) x 898 mm
Programme cycle120/240/360 s
more technical data
UTENSIL WASHERS

MEIKO M-iClean PF-S LH
Rack dimension 608 x 700 mm
Entry height 665 mm
Dimensions (W x Hmin x D)775 x 1868 (2095) x 898 mm
Programme cycle120/240/360 s
more technical data
MEIKO M-iClean PF-S

From racks and crates to rolling pins, food-focused businesses use a huge range of washware that must be cleaned and returned to action as quickly as possible. The challenge of washing these items lies in the sheer variety of shapes, sizes, materials and residues. This echoes the diversity of the food sector itself, which includes everything from bakers' and butchers' window displays to hotel kitchens and food retailers.

Measurements
Rack dimension 608 x 700 mm
Entry height 830 mm
Dimensions (W x Hmin x D)775 x 1868 (2271) x 898 mm
Programme cycle120/240/360 s
Rack capacity/h (theoretical)30/15/10 racks/h
Tank filling66 l
Rinse water volume4,5 liters/cycle
Total connected load8,6 / 10,6 / 11,5 / 17,6 kW
Local fuse protection16 / 20 / 25 / 32 A
Boiler heating6,00 / 8,00 / 9,00 /9,00 A
Tank heating6,00 / 6,00 / 6,00 /6,00 A
M-iClean PF-S LH
Measurements
Rack dimension 608 x 700 mm
Entry height 665 mm
Dimensions (W x Hmin x D)775 x 1868 (2095) x 898 mm
Programme cycle120/240/360 s
Rack capacity/h (theoretical)30/15/10 racks/h
Tank filling66 l
Rinse water volume4,5 liters/cycle
Total connected load8,6 / 10,6 / 11,5 / 17,6 kW
Local fuse protection16 / 20 / 25 / 32 A
Boiler heating6,00 / 8,00 / 9,00 /9,00 A
Tank heating6,00 / 6,00 / 6,00 /6,00 A

CHEMICALS

MEIKO ACTIVE R-GS 2410 GLASS

Sparkling glasses and decor with no need to polish by hand. That is what our highly concentrated rinse aid for soft water can achieve for you. Don't lose any precious time that your staff could use elsewhere – like looking after your customers.

Product data sheetSafety data sheet

MEIKO ACTIVE R-US 2000 ECO

Sustainability is a priority for MEIKO in every area, including cleaning agents. Our ECO rinse aid was developed for just that – maximum eco credentials without compromising on sparkling washing results or flawless hygiene. Both are still guaranteed. Even better: it all comes with no need to polish by hand.

Product data sheetSafety data sheet

MEIKO ACTIVE R-PM 2690 PL

Washing plastic dishes is a unique art form, especially when it comes to drying. This liquid rinse aid was developed to guarantee flawless results when washing plastic dishware. But it doesn't stop there: this versatile rinse aid is also suitable for use with other materials. For hygienic, sparkling, dry washware.

Product data sheetSafety data sheet

MEIKO ACTIVE R-UH 2890

Some water types are difficult to manage and require cleaning products precisely tailored to the situation. In these cases, the acid formula of our highly concentrated rinse aid really comes into its own. That means that even when conditions are not ideal, you can be sure of hygienically clean washing results and sparkling glasses.

Product data sheetSafety data sheet

DOWNLOADS

M-iClean PF Installation instructions

Operating instructions
