DV / FV SERIES

MEIKO's universal warewashers offer outstanding performance!

Wave water
DV 270.2

Rack dimension 1310 x 690 mm1310 x 690 mm
Passing height650 mm650 mm
Dimensions (W x Hmin x D)1490 (1600) x 1792 x 995 (1100) mm (mit Haubenbüge mm1490 (1600) x 1792 x 995 (1100) mm (mit Haubenbüge mm
Programme cycle120 / 240 / 480 s120 / 240 / 480 s
FV 130.2

Rack dimension 850 x 700 mm850 x 700 mm
Entry height 740 mm740 mm
Dimensions (W x Hmin x D)1030 x 1785 x 895 mm1030 x 1785 x 895 mm
Programme cycle120 / 240 / 360 s120 / 240 / 360 s
FV 250.2

Rack dimension 1310 x 700 mm1310 x 700 mm
Entry height 890 mm890 mm
Dimensions (W x Hmin x D)1490 x 1935 x 895 mm1490 x 1935 x 895 mm
Programme cycle120 / 240 / 480 s120 / 240 / 480 s
DV 270.2

This commercial dishwasher has everything it needs to makes it a true all-rounder: That means everything runs more smoothly in the dishwashing area. Uncompromising power effect means there is no need for manual cleaning! The flat tables ensure that there are no idle times – the personnel work in an ergonomically sensible manner.

Measurements
Pot washer DV 270.2
Rack dimension 1310 x 690 mm1310 x 690 mm
Passing height650 mm650 mm
Dimensions (W x Hmin x D)1490 (1600) x 1792 x 995 (1100) mm (mit Haubenbüge mm1490 (1600) x 1792 x 995 (1100) mm (mit Haubenbüge mm
Programme cycle120 / 240 / 480 s120 / 240 / 480 s
Rack capacity/h (theoretical)30 / 15 / 7 racks/h30 / 15 / 7 racks/h
Tank filling100.0 l100.0 l
Rinse water volume9.0 Lite liters/cycle9.0 Lite liters/cycle
Total connected load22,9 kW22,9 kW
Boiler heating18.00 kW / 25.98 A18.00 kW / 25.98 A
Tank heating9.00 kW / 12.99 A9.00 kW / 12.99 A
Wash pump2.20 kW / 4.90 A2.20 kW / 4.90 A
Protection class of the machineIP X5 IP X5
FV 130.2

The FV 130.2 is a commercial dishwasher that offers impressive technical features and enough room to accommodate even the bulkiest items of washware. This powerful all-rounder can even confidently handle pans with burnt-on food. The fully electronic MIKE 2 control system ensures that the oscillating wash arms work in perfect harmony with the tried-and-tested rotating arm rinse system to get every type of washware brilliantly clean.

Measurements
Dimensions of FV 130.2
Rack dimension 850 x 700 mm850 x 700 mm
Entry height 740 mm740 mm
Dimensions (W x Hmin x D)1030 x 1785 x 895 mm1030 x 1785 x 895 mm
Programme cycle120 / 240 / 360 s120 / 240 / 360 s
Rack capacity/h (theoretical)30 / 15 / 10 racks/h30 / 15 / 10 racks/h
Tank filling85.0 l85.0 l
Rinse water volume5.8 Lite liters/cycle5.8 Lite liters/cycle
Total connected load14,7 kW14,7 kW
Boiler heating12.00 kW / 17.32 A12.00 kW / 17.32 A
Tank heating6.00 kW / 8.66 A6.00 kW / 8.66 A
Wash pump2.20 kW / 4.90 A2.20 kW / 4.90 A
Protection class of the machineIP X5 IP X5
FV 250.2

A commercial dishwasher that pushes warewashing to the next level. It is equipped with the Point2 AirConcept. Its intelligent heat recovery system keeps the atmosphere in the dishwashing area pleasant at all times, even when the machine is in constant use. This powerful machine makes light work of all kinds of washware, from pots and pans to trays, kitchen utensils, containers and bowls.

Measurements
Dimensions of FV 250.2
Rack dimension 1310 x 700 mm1310 x 700 mm
Entry height 890 mm890 mm
Dimensions (W x Hmin x D)1490 x 1935 x 895 mm1490 x 1935 x 895 mm
Programme cycle120 / 240 / 480 s120 / 240 / 480 s
Rack capacity/h (theoretical)30 / 15 / 7 racks/h30 / 15 / 7 racks/h
Tank filling100.0 l100.0 l
Rinse water volume9.0 Lite liters/cycle9.0 Lite liters/cycle
Total connected load22,9 kW22,9 kW
Boiler heating18.00 kW / 25.98 A18.00 kW / 25.98 A
Tank heating9.00 kW / 12.99 A9.00 kW / 12.99 A
Wash pump2.20 kW / 4.90 A2.20 kW / 4.90 A
Protection class of the machineIP X5 IP X5

* If the machine is connected to a cold water supply and/or if racks are inserted in quick succession, the duration of the wash cycles may be increased to achieve hygienic final rinse temperatures.
Product lines and configurations may vary from one country to the next due to statutory requirements or other reasons. Please check with us. They will be happy to find a machine that meets your specific requirements.
Date: 03.2017. Technical modifications reserved.



Punkt2 AirConcept M-iQ
Heat recovery to enhance air qualitiy and energy efficiency

AirConcept is MEIKO's innovative air management system. It uses heat recovery to ensure a pleasant indoor climate.

fine filtration system - AktivPlus
Cost-cutting filter system for dishwashing equipment

MEIKO's cost-cutting filter system

M-iQ self-cleaning
Self-cleaning commercial dishwashing system

After the warewashing process, the M-iQ cleans itself with the tank water already inside, greatly reducing operating costs.
